80GHz FMCW Radar Water Level Gauge Transmitter Non Contact For Hydrological Detection

Brand Name:	KaiNaFu
Model Number:	KNF-1311
MOQ:	1 pieces
Packaging Details:	Environmentally friendly cardboard box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen

Document:

Measurement Principle:

80GHz Millimeter-wave Radar

Ranging Range:

0.1~40m

Measurement Accuracy:

Resolution:

Supply Ability:

300 pieces+One month

Highlight:

FMCW Radar Water Level Sensor

80GHz Radar Water Level Sensor

80GHz non contact level transmitter

Product Description

Radar Water Level Gauge Features Non-contact Installation With RS485 Output Accuracy And Low Power Consumption

The KNF-1311 series millimeter-wave radar is a radar specifically designed by Kenafu for hydrological detection. This radar adopts FMCW mode, features a non-contact installation design, is compact in size, has a tight structure, high precision, low power consumption and strong anti-interference ability. The lens is made of polytetrafluoroethylene, featuring high measurement accuracy and strong reliability. Meanwhile, the lens has anti-adhesion performance, which can effectively prevent flowing materials from adhering to the antenna. With an IP68 waterproof design, it is widely applicable for liquid level monitoring in lakes, rivers, mountain flood warnings, reservoirs, sewage networks, etc. Meanwhile, the KNF-1311A adopts built-in battery power supply and 4G/NB wireless transmission function, with a service life of 3 to 5 years. It is equipped with a cloud monitoring platform and an APP for real-time monitoring and early warning.

80GHz FMCW Radar Water Level Gauge Transmitter Non Contact For Hydrological Detection 0

Technical indicators

Parameters/Product model	KNF-1311
Measurement principle	80GHz millimeter-wave radar
Ranging range	0.1~40m
Measurement accuracy	±5mm
Resolution	1mm
Start-up time	Approximately 100ms
Output	RS485
Power supply	12-24DCV
Overall dimensions (diameter x height)	Φ75x82 mm (Excluding installation accessories)
Shell material	POM or PVC
Lens material	Polytetrafluoroethylene (anti-corrosion and anti-adhesion)
Weight	About 160g
Monitoring cloud platform APP	Optional
Usage environment	-40~70℃
Protection grade	IP68
